HY-5003 MASTECH Single Variable DC Power Supply Digital 0-50VDC@0-3A
Professional regulated DC power supply from Mastech, Model HY-5003. This highly stable, high quality linear DC power supply with its output continously adjustable at 0-50V DC and 0-3A. What's more, the unit is equiped with coarse and fine controls for adjusting the voltage and current outputs, making it easy to set the output to your desired level. The unit comes with 2 LED displays, providing accurate readout for the voltage and current values.
Features & Specifications:
Adjustable outputs: 0-50V and 0-3A
Coarse and fine controls for both current and voltage outputs
Input voltage: 110V/220V switchable
Line regulation: CV <= 0.01% + 1 mV, CC <= 0.2% + 1 mA
Load Regulation: CV <= 0.01% + 3mV, CC <= 0.2% + 3 mA
Ripple noise: CV <= 0.5 mV RMS, CC <= 3 mA RMS
Protection: constant current and short-circuit protection
LCD reading accuracy: +/-1% for voltage and +/-2% for current
Environment: 0-40C, relative humidity < 90%
Size: 9.1" x 6.4" x 3.8"
